Magento Web API is a crucial feature of Magento which supports developers using web services that communicate with the Magento system. For instance, a developer can create a customer account and product record through web service.
Magento Web API framework includes the following features:
- It supports both REST (Representational State Transfer) and SOAP (Simple Object Access Protocol)
- Magento Web API requires authentication to perform any task. There are 3 types of authentication:
Token-Based Authentication based on REST and SOAP
Oauth-Based Authentication based on OAuth 1.0a
Session-Based Authentication based on the current logged-in session of admin/customer
Here, in this article, I will explain to you about REST Web API.
Construct A Request:
There are many Web APIs in Magento, which are defined in webapi.xml file of a module that is <module root dir>/vendor/<vendor-name>/<module-name>/etc/webapi.xml, where <vendor-name> is a vendor name (e.g. Magento) and <module-name> is a module name (e.g. module-customer). For example, the web API for the Customer service is defined in the <Magento dir>/vendor/magento/module-customer/etc/webapi.xml.
A Web API call has the following elements to perform an action:
- HTTP verb – The action to perform against the endpoint. There are:
GET (default) PUT POST DELETE
- Endpoint – An endpoint is a combination of the server that fulfils a request, the web service, the store code, the resource against which the request is being made, and any template parameters.
To create the endpoint in the call –
https://<MAGENTO_HOST_OR_IP>/<MAGENTO_BASE_INSTALL_DIR>/rest/
For instance:
For instance –
http://your-domain.com/index.php/rest/default/V1/customerGroups/:id
Here,
your-domain.com/index.php/ is the server name
rest is the name of web service
default is the code of the default store of Magento Store. It can be a code of a specific code or all can be specified to perform an action on all stores.
V1/customerGroups is the resource
id is a template parameter
- HTTP Headers – These are:
Authorization: It is required and specifies the token for authentication.
Accept: Optionally specifies the format of responses json (default) and xml.
Content-Type: It is required if the request body is specified. Format of request body can either be json or xml.
- Call Payload – It is a set of input parameters and attributes that are supplied with the request. This is actually a request body in either json or xml format.
REST Web APIs are run through cURL. CURL is a command-line tool that lets you transmit and receive HTTP requests and responses from the command line or a shell script.
Making a Web API call requires an authenticated token for the cURL requests for admin and customer. Following are the REST URLs:
- Admin Token – POST /V1/integration/admin/token
- Customer Token – POST /V1/integration/customer/token
Following is the code to retrieve a token for admin –
<?php
$adminData = array("username" => "admin", "password" => "admin@1234");
$ch = curl_init("http://your-domain.com/index.php/rest/V1/integration/admin/token"); curl_setopt($ch, CURLOPT_CUSTOMREQUEST, "POST");
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($userData));
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_HTTPHEADER, array("Content-Type: application/json", "Content-Length: " . strlen(json_encode($adminData))));
$token = curl_exec($ch);
curl_close($ch); This code will assign Admin Token to $token variable.
Now, the following is the code to create a new customer account:
<?php
/*********CREATE A CUSTOMER ACCOUNT*************/
$post = '{
"customer": {
"email": "[email protected]",
"firstname": "John",
"lastname": "Doe"
},
"addresses": [{
"defaultShipping": true,
"defaultBilling": true,
"firstname": "John",
"lastname": "Doe",
"region": {
"regionCode": "CA",
"region": "California",
"regionId": 12
},
"postcode": "90001",
"street": ["Zoe Ave"],
"city": "Los Angeles",
"telephone": "555-000-00-00",
"countryId": "US"
}],
"password": "test@1234"
}';
$ch = curl_init("http://your-domain.com/index.php/rest/V1/customers");
curl_setopt($ch, CURLOPT_CUSTOMREQUEST, "POST");
curl_setopt($ch, CURLOPT_POSTFIELDS, $post);
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_HTTPHEADER, array("Content-Type: application/json", "Authorization: Bearer " . json_decode($token)));
$result = curl_exec($ch); echo '<pre>'; print_r(json_decode($result));
echo '</pre>'; curl_close($ch);
/*********CREATE A CUSTOMER ACCOUNT ENDS HERE*************/For the above example to create a customer account, REST Web API call has been constructed in the following way:
- Open <Magento Dir>/vendor/module-customer/etc/webapi.xml file.
- Find the route element that defines createAccount call –
<route url="/V1/customers" method="POST">
<service class="Magento\Customer\Api\AccountManagementInterface" method="createAccount"/>
<resources>
<resource ref="anonymous"/>
</resources>
</route>Here, the endpoint of cURL request has resource – V1/customers, which is the same as the route url defined above under url attribute in the <route> tag.
- Now, open <Magento Dir>/vendor/module-customer/Api/AccountManagementInterface.php file.
Here, you will see a function:
public function createAccount(\Magento\Customer\Api\Data\CustomerInterface $customer, $password = null, $redirectUrl = '');
There are 3 parameters of createAccount function -
$customer – is a data object which is required.
$password – is optional
$redirectUrl – is optional To pass the customer data object in the POST call payload, specify JSON or XML request body on the call.
The following code is used to retrieve information about the customer:
<?php
/*****VIEW A CUSTOMER RECORD*********/
$ch = curl_init("http://your-domain.com/index.php/rest/V1/customers/1"); curl_setopt($ch, CURLOPT_CUSTOMREQUEST, "GET");
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_HTTPHEADER, array("Content-Type: application/json", "Authorization: Bearer " . json_decode($token)));
$result = curl_exec($ch);
echo '<pre>';
print_r(json_decode($result));
echo '</pre>'; curl_close($ch);
exit();
/*****VIEW A CUSTOMER RECORD ENDS HERE*********/
Here, this code will fetch the record of customer having ID – 1. Following is the code to retrieve the information about a product:
<?php /*****VIEW A PRODUCT RECORD*********/
$request = "http://your-domain.com/index.php/rest/V1/products/24-MB01";
$ch = curl_init($request);
curl_setopt($ch, CURLOPT_CUSTOMREQUEST, "GET");
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_HTTPHEADER, array("Content-Type: application/json", "Authorization: Bearer " . json_decode($token)));
$result = curl_exec($ch);
echo '<pre>';
print_r($result);
echo '</pre>';
curl_close($ch);
/*****VIEW A PRODUCT RECORD ENDS HERE*********/Here, this code will fetch the record of the product with the code – 24-MB01.
I hope that this article was helpful. I will continue to explain more about SOAP and OAuth in the next article.
